Same model may have multiple batches, images only for reference.
B45197A3686K409 Real Image
Same model may have multiple batches, images only for reference.

B45197A3686K409

Part No B45197A3686K409
Manufacturer Kemet
Catalog Ceramic Capacitors
Description Cap 68UF 16VDC 10% 7.3 X 4.3 X 2.8MM SMD 7343-31 T/r
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Capacitance 68 µF
Mounting SMD (SMT)
Case / Package 1206
Case Code (Imperial) 1206
Case / Package 3216
Depth 4.3 mm
Dissipation Factor 6 %
ESR (Equivalent Series Resistance) 250 mΩ
Height 1.8 mm
Lead Free Yes
Length 3.2 mm
Maximum Operating Temperature 125 °C
Min Operating Temperature -55 °C
Polarity Polar
RoHS Compliant
Termination SMD/SMT
Tolerance 10 %
Voltage Rating 16 V
Voltage Rating (DC) 16 V
Width 1.6 mm
Win Source Part Number 1047756-B45197A3686K409
Categories Ceramic Capacitors
Manufacturer Kemet
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian B45197A3686K409 CAD Model

Description

The Kemet 1047756-B45197A3686K409 is a high-quality ceramic capacitor designed for use in a wide range of electronic devices.

  • Capacitance: 68 µF
  • Voltage Rating: 16 V
  • Size: 3.2 mm x 1.6 mm x 1.8 mm
  • Tolerance: 10%
  • ESR: 250 mΩ
  • Dissipation Factor: 6%
