Same model may have multiple batches, images only for reference.
ALF80C511DF400 Real Image
Same model may have multiple batches, images only for reference.

ALF80C511DF400

Part No ALF80C511DF400
Manufacturer Kemet
Catalog Aluminum Capacitors
Description CAP ALUM 510UF 20% 400V SNAP / 510 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Press-Fit - 4 Lead 242mOhm @ 100Hz 8000 Hrs @ 105°C
Datasheet
ALF80C511DF400 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Capacitors>Aluminum Electrolytic Capacitors
Mfr KEMET
Series ALF80
Package Bulk
Capacitance 510 µF
Tolerance ±20%
Voltage - Rated 400 V
ESR (Equivalent Series Resistance) 242mOhm @ 100Hz
Lifetime @ Temp. 8000 Hrs @ 105°C
Temperature Range - Operating -40°C ~ 105°C
Polarization Polar
Applications General Purpose
Ripple Current @ Low Frequency 2.74 A @ 100 Hz
Ripple Current @ High Frequency 7.36 A @ 10 kHz
Impedance 125 mOhms
Lead Spacing 0.886" (22.50mm)
Dimension 1.378" Dia (35.00mm)
Height - Seated (Max) 2.047" (52.00mm)
Mounting Type Through Hole, Press-Fit
Package / Case Radial, Can - Press-Fit - 4 Lead
Base Product Number ALF80C
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8532.22.0040
Other Names 399-ALF80C511DF400
Standard Package 100
Win Source Part Number 1034478-ALF80C511DF400
Ultra Librarian 3D Model Ultra Librarian ALF80C511DF400 CAD Model

Description

The ALF80 series from KEMET is an aluminum electrolytic capacitor designed for general-purpose applications.

  • Manufacturer: KEMET
  • Series: ALF80
  • Capacitance: 510 µF
  • Voltage Rating: 400 V
  • Tolerance: ±20%
  • ESR: 242mOhm @ 100Hz
  • Impedance: 125 mOhms
  • Package: Bulk
  • Standard Package: 100
  • Package/Case: Radial, can - press-fit - 4 lead
  • Temperature Range: -40°C to 105°C
  • Lifetime: 8000 Hrs @ 105°C
  • Dimensions: 1.378" Dia (35.00mm)
  • ECCN: EAR99
