BM03B-ACHFKS-GACN-ETF(LF)(SN) Real Image
Same model may have multiple batches, images only for reference.

BM03B-ACHFKS-GACN-ETF(LF)(SN)

Part No BM03B-ACHFKS-GACN-ETF(LF)(SN)
Manufacturer JST Sales America Inc.
Catalog Rectangular Connectors
Description CONN HEADER SMD R/A 3POS 1.2MM / Connector Header Surface Mount, Right Angle 3 position 0.047" (1.20mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr JST Sales America Inc.
Series ACHF
Package Tape & Reel
Connector Type Header
Contact Type Male Blade
Pitch - Mating 0.047" (1.20mm)
Number of Positions 3
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 3 Wall
Mounting Type Surface Mount, Right Angle
Termination Solder
Fastening Type Detent Lock
Insulation Height 0.056" (1.43mm)
Contact Shape Rectangular
Contact Finish - Mating Gold
Contact Material Copper Alloy
Insulation Material Polymer
Features Solder Retention
Temperature Range - Operating -25°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 2.5A
Voltage Rating 50V
Base Product Number BM03B-AC
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 455-2899-6,BM03BACHFKSGACNETFLFSN,455-2899-2,455-2899-1
Standard Package 6,000
Win Source Part Number 1003353-BM03B-ACHFKS-GACN-ETF(LF)(SN)
Ultra Librarian 3D Model Ultra Librarian BM03B-ACHFKS-GACN-ETF(LF)(SN) CAD Model

Description

The BM03B-ACHFKS-GACN-ETF(LF)(SN) is a 3 position header connector with male blade contact type.

  • Connector Type: Solder retention
  • Contact Material: Copper alloy
  • Voltage Rating: 50V
  • Current Rating: 2.5A
  • Style: Board to cable/wire
  • Pitch-Mating: 0.047" (1.20mm)
  • Mounting: Surface mount with right angle mounting type
  • Shrouding: Shrouded-3 wall
  • Packaging: Tape & reel
  • Standard Package: 6,000
