MOC3060XSM Real Image
Same model may have multiple batches, images only for reference.

MOC3060XSM

Part No MOC3060XSM
Manufacturer Isocom Components 2004 LTD
Catalog Optoisolators - Triac, SCR Output
Description OPTOISOLATOR 5.3KV TRIAC 6SMD / Optocoupler Triac AC-OUT 1-CH 600V 6-Pin PDIP SMD
Datasheet
MOC3060XSM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Isocom Components 2004 LTD
Packaging Tube
Output Type Triac
Zero Crossing Circuit Yes
Number of Channels 1
Voltage - Isolation 5300Vrms
Voltage - Off State 600V
Static dV/dt (Minimum) 600V/μs
Current - LED Trigger (Ift) (Maximum) 30mA
Current - Hold (Ih) 400μA (Typ)
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Maximum) 50mA
Operating Temperature Range -40°C ~ 100°C
Mounting SMD
Package 6-SMD, Gull Wing
Approvals UR, VDE
Win Source Part Number 789071-MOC3060XSM
Popularity Medium
Supply and Demand Status Limited
Quantity per package 1,300
Family Name MOC3060
Introduction Date September 20, 2002
ECCN EAR99
Country of Origin Thailand
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian MOC3060XSM CAD Model

Description

The MOC3060XSM electronic component is an isolator manufactured by Isocom Components 2004 LTD.

  • Package: 6-SMD, Gull Wing
  • Off-State Voltage: 600V
  • Zero Crossing Circuit: Yes
  • Output Type: Triac
  • Alternative Parts: MOC3060XG, MOC3060X, MOC3060XSMT&R
  • Operating Temperature: -40°C ~ 100°C
  • EOL Date: 2026
