CNY17-4XSM Real Image
Same model may have multiple batches, images only for reference.

CNY17-4XSM

Part No CNY17-4XSM
Manufacturer Isocom Components 2004 LTD
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTICALLY COUPLED ISOLATOR PHOTOTRANSISTOR OUTPUT
Datasheet
CNY17-4XSM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Isocom Components 2004 LTD
Packaging Tube
Number of Channels 1
Voltage - Isolation 5300Vrms
Current Transfer Ratio (Minimum) 160% @ 10mA
Current Transfer Ratio (Maximum) 320% @ 10mA
Turn On / Turn Off Time (Typ) 3μs, 2.3μs
Rise / Fall Time (Typ) 2μs, 2μs
Input Type DC
Output Type Transistor with Base
Output Voltage MAX 70V
Output Current per Channel 50mA
Voltage - Forward (Vf) (Typ) 1.2V
Current - DC Forward (If) (Maximum) 60mA
Vce Saturation (Maximum) 400mV
Operating Temperature Range -55°C ~ 100°C
Mounting SMD
Package 6-SMD, Gull Wing
Manufacturer Package 6-SMD
Win Source Part Number 1162640-CNY17-4XSM
Manufacturer Homepage www.isocom.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Automation & Process Control, Communications & Networking, Industrial
Family Name CNY17-4X
Introduction Date July 30, 1997
ECCN EAR99
Country of Origin Thailand
Estimated EOL Date 2023
Quantity per package 1,300
Ultra Librarian 3D Model Ultra Librarian CNY17-4XSM CAD Model

Description

The CNY17-4XSM component is manufactured by Isocom Components 2004 LTD and is part of the Win Source Part Number series.

  • Component: Isolator
  • Voltage-Isolation: 5300Vrms
  • Current-Transfer Ratio: Minimum 160% @ 10mA and maximum 320% @ 10mA
