Same model may have multiple batches, images only for reference.

EV1380QI

Name: EV1380QI
Brand: Intel
SKU: 590256
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	EV1380QI
Manufacturer	Intel
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER 0.58-0.825V
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Intel
Series	Enpirion®
Package	Tape & Reel
Product Status	Obsolete
Type	Non-Isolated PoL Module
Number of Outputs	1
Voltage - Input (Min)	1.16V
Voltage - Input (Max)	1.65V
Voltage - Output 1	0.58 ~ 0.825V
Current - Output (Max)	8A
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, OTP, SCP, UVLO
Temperature Range - Operating	-40°C ~ 85°C
Efficiency	94%
Mounting Type	Surface Mount
Package / Case	68-BFQFN Exposed Pad, Module
Size / Dimension	0.43" L x 0.32" W x 0.12" H (11.0mm x 8.0mm x 3.0mm)
Supplier Device Package	68-QFN (11x8)
Control Features	Enable, Active High
Base Product Number	EV1380
Standard Package	250 pcs
MSL Level	3 (168 Hours)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	590256-EV1380QI
Ultra Librarian 3D Model	Ultra Librarian EV1380QI CAD Model

Alternative Products

Description

The EV1380QI is a non-isolated PoL module from the Enpirion series by Intel.

Application: Power supply for commercial information technology equipment
Features: Remote on/off, Over Current Protection (OCP), Over Temperature Protection (OTP), Short Circuit Protection (SCP), and Under Voltage Lockout (UVLO)
Size: 11.0mm x 8.0mm x 3.0mm
Voltage Input Range: 1.16V to 1.65V
Maximum Output Current: 8A
Efficiency: 94%
Operating Temperature: -40°C to 85°C
Status: Obsolete
