Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Embedded - FPGAs (Field Programmable Gate Array)
Mfr Intel
Series MAX® 10
Package Tray
Number of LABs/CLBs 1000
Number of Logic Elements/Cells 16000
Total RAM Bits 562176
Number of I/O 101
Voltage - Supply 2.85V ~ 3.465V
Mounting SMD (SMT)
Temperature Range - Operating 0°C ~ 85°C (TJ)
Package / Case 144-LQFP Exposed Pad
Supplier Device Package 144-EQFP (20x20)
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991D
HTSUS 8542.39.0001
Other Names 965609,544-3111
Standard Package 60
Win Source Part Number 1034363-10M16SCE144C8G
Ultra Librarian 3D Model Ultra Librarian 10M16SCE144C8G CAD Model

Description

The MAX® 10 series from Intel is an integrated circuit that is designed for use in embedded field programmable gate array (FPGA) applications.

  • Package: 144-LQFP Exposed Pad
  • Mounting: SMD (SMT)
  • I/Os: 101
  • LABs/CLBs: 1000
  • Logic Elements/Cells: 16000
  • Total RAM bit: 562176
  • Voltage: 2.85V ~ 3.465V
  • Lead-Free: Yes
  • RoHS Compliant: Yes
  • REACH Regulations: Unaffected
  • Supply and Demand: Shortage
  • Popularity: Low
