Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Manufacturer Intel
Packaging Tray
Number of LABs/CLBs 125
Number of Logic Elements/Cells 2000
Total RAM Bits 110592
Number of I/O 101
Supply Voltage (V) 2.85V ~ 3.465V
Mounting Style SMD
Temperature Range - Operating 0°C ~ 85°C
Manufacturer Package 144-LQFP Exposed Pad
Supplier Device Package 144-EQFP (20x20)
Manufacturer Pack Quantity 60
MSL Level 3 (168 Hours)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 805824-10M02SCE144C8G
Ultra Librarian 3D Model Ultra Librarian 10M02SCE144C8G CAD Model

Description

The Intel 805824-10M02SCE144C8G is a SMD mounting style component that comes with 101 I/O and 125 LABs/CLBs. It is manufactured by Intel.

  • I/O: 101
  • LABs/CLBs: 125
  • Logic Elements/Cells: 2000
  • Total RAM Bits: 110592
  • Package: 144-EQFP (20x20)
  • Operating Temperature: 0°C to 85°C
  • Supply Voltage: 2.85V ~ 3.465V
  • Popularity: Medium
  • Supply and Demand Status: Balanced
