IPS511GTR Infineon Technologies IPS511GTR Real Image IPS511GTR real image211
Same model may have multiple batches, images only for reference.
IPS511GTR Infineon Technologies IPS511GTR Real Image IPS511GTR real image211
IPS511GTR Infineon Technologies IPS511GTR Real Image IPS511GTR real image211
Same model may have multiple batches, images only for reference.

IPS511GTR

Part No IPS511GTR
Manufacturer Infineon Technologies
Catalog PMIC - Power Distribution Switches, Load Drivers
Description IC MOSFET HS PWR SW 5A 8-SOIC
Datasheet
IPS511GTR Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Switch Type General Purpose
Number of Outputs 1
Output Type N-Channel
Voltage - Load 5.5 V to 35 V
Supply Voltage - Operating Not Required
Current - Output (Max) 1.4A
Rds On (Typ) 130 mOhm
Input Type Non-Inverting
Features Auto Restart
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package 8-SO
Win Source Part Number 017329-IPS511GTR
Family Name IPS511
Introduction Date April 28, 2000
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian IPS511GTR CAD Model

Description

The Infineon Technologies IPS511GTR is an integrated circuit that features auto restart, current limiting (fixed), open load detect, and over temperature fault protection.

  • Output Type: Single
  • Maximum Current Output: 1.4A
  • Voltage Load Range: 5.5V to 35V
  • Input Type: Non-inverting
  • Switch Type: General Purpose
  • Status: Currently obsolete (EOL)
  • Supply and Demand Status: Balance
  • Package: 8-SO
  • Supply Voltage Operating Range: Not required
