IKW30N65EL5XKSA1

Name: IKW30N65EL5XKSA1
Brand: Infineon Technologies
SKU: 1022137
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IKW30N65EL5XKSA1
Manufacturer	Infineon Technologies
Catalog	IGBTs - Single
Description	IGBT 650V 30A FAST DIODE TO247-3 / IGBT 650 V 85 A 227 W Through Hole PG-TO247-3
Datasheet	IKW30N65EL5XKSA1 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - IGBTs - Single
Mfr	Infineon Technologies
Series	TrenchStop™ 5
Package	Tube
Voltage - Collector Emitter Breakdown (Max)	650 V
Current - Collector (Ic) (Max)	85 A
Current - Collector Pulsed (Icm)	120 A
Vce(on) (Max) @ Vge, Ic	1.35V @ 15V, 30A
Power - Max	227 W
Switching Energy	470µJ (on), 1.35mJ (off)
Input Type	Standard
Gate Charge	168 nC
Td (on/off) @ 25°C	33ns/308ns
Test Condition	400V, 30A, 10Ohm, 15V
Reverse Recovery Time (trr)	100 ns
Temperature Range - Operating	-40°C ~ 175°C (TJ)
Mounting Type	Through Hole
Package / Case	TO-247-3
Supplier Device Package	PG-TO247-3
Base Product Number	IKW30N65
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Other Names	IKW30N65EL5XKSA1IN,SP001178080
Standard Package	30
Win Source Part Number	1022137-IKW30N65EL5XKSA1
Ultra Librarian 3D Model	Ultra Librarian IKW30N65EL5XKSA1 CAD Model

Alternative Products

Description

The IKW30N65EL5XKSA1 is a single IGBT transistor from Infineon Technologies.

Series: TrenchStop™ 5
Maximum Power Rating: 227 W
Reverse Recovery Time: 100 ns
Collector-Emitter Voltage Breakdown (Max): 650 V
Maximum Collector Current: 85 A
Pulsed Collector Current: 120 A
Switching Energy: 470µJ (on) and 1.35mJ (off)
Input Type: Standard
Gate Charge: 168 nC
Delay Time: 33ns/308ns @ 25°C
Temperature Range: -40°C to 175°C (TJ)
Package: TO-247-3
Mounting: Through-hole
