RU4S-A24 Real Image
Same model may have multiple batches, images only for reference.

RU4S-A24

Part No RU4S-A24
Manufacturer IDEC
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE 4PDT 6A 24V
Datasheet
RU4S-A24 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Power Relays, Over 2 Amps
Mfr IDEC
Series RU
Package Bulk
Product Status Active
Mounting Type Socketable
Coil Voltage 24VAC
Contact Form 4PDT (4 Form C)
Contact Rating (Current) 6 A
Switching Voltage 250VAC, 30VDC - Max
Coil Current 42.5 mA
Coil Type Non Latching
Features Lighted Indicator, Mechanical Indicator, Test Button
Termination Style Plug In
Must Operate Voltage 19.2 VAC
Must Release Voltage 7.2 VAC
Operate Time 20 ms
Release Time 20 ms
Temperature Range - Operating -55°C ~ 60°C
Contact Material Silver (Ag), Gold (Au)
Relay Type General Purpose
Coil Resistance 164 Ohms
Base Product Number RU4S
Standard Package 1 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.49.0050
California Prop 65 Warning Information
Win Source Part Number 892631-RU4S-A24
Ultra Librarian 3D Model Ultra Librarian RU4S-A24 CAD Model

Description

The IDEC 892631-RU4S-A24 is a power relay component that is designed to handle currents over 2 Amps.

  • Series: RU
  • Termination Style: Plug-in
  • Features: Lighted indicator, mechanical indicator, and test button
  • Package: Bulk
  • Contact Form: 4PDT (4 Form C)
  • Contact Material: Silver (Ag) and Gold (Au)
  • Coil Voltage: 24VAC
  • Coil Resistance: 164 Ohms
  • Contact Rating for Current: 6A
  • Switching Voltage: 250VAC or 30VDC
  • Operating Temperature Range: -55°C to 60°C
  • Manufacturer: IDEC
  • Warning: California Prop 65
