The H5PS1G63JFR-S6CR is a 1Gb DDR2 SDRAM (Double Data Rate 2 Synchronous Dynamic Random-Access Memory) chip manufactured by Hynix Semiconductor. This memory chip is designed for applications requiring high bandwidth and memory capacity. The 1Gb capacity is organized as 64M x 16. DDR2 SDRAM provides improved performance compared to its predecessor, DDR SDRAM, by doubling the data transfer rate for each clock cycle. It is used in various applications requiring fast and efficient memory access.

Applications

• Graphics Cards: Provides memory for storing textures, frame buffers, and other graphical data.
• Gaming Consoles: Supports fast data access for game data and real-time rendering.
• High-Definition Televisions (HDTVs): Used for video processing, buffering, and display functions.
• Set-Top Boxes: Manages data for decoding and displaying multimedia content.
• Networking Equipment: Stores routing tables and packet data in switches and routers.
• Industrial Control Systems: Provides memory for data acquisition and processing.

Features

• 1Gb Capacity: Offers ample memory space for demanding applications.
• DDR2 Interface: Provides high data transfer rates.
• 64M x 16 Organization: Arranges memory cells for efficient access.
• Operating Frequency up to 800MHz: Enables fast data access and processing.
• Double Data Rate: Transfers data on both the rising and falling edges of the clock signal.
• On-Chip DLL (Delay-Locked Loop): Ensures accurate timing and synchronization.
• Write Latency of 3, 4, or 5 Clock Cycles: Allows flexible timing configurations.
• Power-Saving Features: Minimizes power consumption in standby mode.
• Lead-Free Packaging: Meets environmental regulations.

Benefits

• Increased System Performance: High bandwidth and fast access times improve overall system responsiveness.
• Enhanced Graphics Capabilities: Sufficient memory capacity supports complex textures and rendering effects.
• Smoother Video Playback: High data rates ensure seamless video decoding and display.
• Reduced Power Consumption: Power-saving features extend battery life in portable devices.
• Improved Reliability: Robust design and manufacturing processes ensure stable operation.
• Simplified System Design: Standard DDR2 interface simplifies integration with other components.

Additional Details

The H5PS1G63JFR-S6CR typically operates at a voltage of 1.8V. It is available in a FBGA (Fine-Pitch Ball Grid Array) package. The operating temperature range is typically between 0°C and 85°C. The datasheet provides detailed information on timing parameters, electrical characteristics, and package dimensions. It is compliant with JEDEC standards for DDR2 SDRAM. The 'S6CR' likely refers to a specific speed grade, temperature range, and other customer-specific requirements or testing procedures.
