DM1B-DSF-PEJ(92) Hirose Electric Co Ltd
Same model may have multiple batches, images only for reference.

DM1B-DSF-PEJ(92)

Part No DM1B-DSF-PEJ(92)
Manufacturer Hirose Electric Co Ltd
Catalog Memory Connectors - PC Card Sockets
Description CONN MEM SECURE DIGITAL SMD / 12 (9 + 3) Position Card Connector Secure Digital - SD Surface Mount, Right Angle Gold
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Memory Connectors - PC Card Sockets
Mfr Hirose Electric Co Ltd
Series DM1
Package Tape & Reel
Product Status Active
Card Type Secure Digital - SD
Number of Positions 12 (9 + 3)
Connector Type Connector and Ejector
Insertion, Removal Method Push In, Push Out
Ejector Side -
Mounting Type Surface Mount, Right Angle
Features Board Guide, Switch
Height Above Board 0.114" (2.90mm)
Mounting Feature Normal, Standard - Top
Contact Finish Gold
Contact Finish Thickness 7.87µin (0.200µm)
Base Product Number DM1B
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1363481-DM1B-DSF-PEJ(92)
Ultra Librarian 3D Model Ultra Librarian DM1B-DSF-PEJ(92) CAD Model

Description

The Hirose Electric Co Ltd. DM1B-DSF-PEJ(92) is a PC card socket from Hirose Electric Co Ltd..

  • Series: DM1
  • Application: Memory Connectors
  • Mounting Type: Surface Mount, Right Angle
  • Insertion/Removal Method: Push-In, Push-Out
  • Contact Finish: Gold
  • Contact Finish Thickness: 7.87µin (0.200µm)
  • Card Type: Secure Digital (SD)
  • Number of Positions: 12 (9 + 3)
  • RoHS Compliant: Yes
