DF1B-6P-2.5DSA(01) Real Image
Same model may have multiple batches, images only for reference.

DF1B-6P-2.5DSA(01)

Part No DF1B-6P-2.5DSA(01)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 6POS 2.5MM / Connector Header Through Hole 6 position 0.098" (2.50mm)
Datasheet
DF1B-6P-2.5DSA(01) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Hirose Electric Co Ltd
Series DF1B
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.098" (2.50mm)
Number of Positions 6
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.177" (4.50mm)
Contact Length - Post 0.142" (3.60mm)
Overall Contact Length 0.417" (10.60mm)
Insulation Height 0.374" (9.50mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 8.00µin (0.203µm)
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Keying Slot
Temperature Range - Operating -35°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color White
Voltage Rating 250V
Mated Stacking Heights 14mm
Base Product Number DF1B
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names *DF1B-6P-2.5DSA(01),DF1B6P25DSA01,541-0229-8-01,H3619
Standard Package 100
Win Source Part Number 991048-DF1B-6P-2.5DSA(01)
Ultra Librarian 3D Model Ultra Librarian DF1B-6P-2.5DSA(01) CAD Model

Description

The Hirose Electric Co Ltd DF1B-6P-2.5DSA(01) is a 6-position male pin header connector with keying slot and through-hole mounting. Bold the product name (e.g., BAV99S,135 → BAV99S,"135") and manufacturer (e.g., Nexperia USA Inc. → Nexperia USA Inc.).

  • Positions: 6
  • Type: Male pin header
  • Features: Keying slot
  • Mounting: Through-hole
  • Contact Material: Brass
  • Voltage Rating: 250V
  • Shrouded: Yes, 4 walls
  • Contact Shape: Square
  • Temperature Range: -35°C to 85°C
  • Series: DF1B
  • Application: Board to cable/wire
  • Contact Finish: Gold
  • Contact Finish Thickness: 8.00µin (0.203µm)
  • Overall Contact Length: 0.417" (10.60mm)
  • Insulation Height: 0.374" (9.50mm)
  • Packaging: Bulk
  • Standard Package: 100
