The Hirose Electric Co Ltd A3B-14PA-2DSA(71) is a male pin header connector that comes with 14 positions and a header connector type.

• Positions: 14
• Connector Type: Header
• Positions Loaded: All
• Number of Rows: 2
• Termination Type: Solder
• Fastening Type: Push-Pull
• Package: Tray
• Contact Material: Brass
• Voltage Rating: 200VAC
• Insulation Material: Polyamide (PA), Nylon
• Pitch-Mating: 0.079 inches (2.00mm)
• Contact Finish: Gold
• Contact Finish Thickness-Mating: Flash
• Contact Finish-Post: Tin
• Contact Finish Thickness-Post: 78.7μin (2.00μm)
• Insulation Color: Black
• Mounting Type: Through-Hole
• Shrouding: Unshrouded
• Row Spacing-Mating: 0.079 inches (2.00mm)
• Contact Length-Post: 0.102 inches (2.60mm)
• Contact Length Overall: 0.311 inches (7.90mm)
• Insulation Height: 0.071 inches (1.80mm)
• Contact Shape: Square
• Operating Temperature: -55°C to 85°C
• Current Rating (Amps): 1A
• ECCN: EAR99
• HTSUS: 8536.69.4040
• Product Status: Obsolete
