M22-2011205 Real Image
Same model may have multiple batches, images only for reference.

M22-2011205

Part No M22-2011205
Manufacturer Harwin Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 12POS 2MM / Connector Header Through Hole 12 position 0.079" (2.00mm)
Datasheet
M22-2011205 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Harwin Inc.
Series M22
Package Bulk
Connector Type Header, Cuttable
Contact Type Male Pin
Pitch - Mating 0.079" (2.00mm)
Number of Positions 12
Number of Rows 1
Number of Positions Loaded All
Style Board to Board
Shrouding Unshrouded
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.138" (3.50mm)
Contact Length - Post 0.134" (3.40mm)
Overall Contact Length 0.331" (8.40mm)
Insulation Height 0.059" (1.50mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Material Phosphor Bronze
Insulation Material Polyamide (PA6T), Nylon 6T
Temperature Range - Operating -55°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 1A per Contact
Mated Stacking Heights 5.9mm, 8.6mm
Base Product Number M22-201
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names M22-2011205-ND,952-3312,M22F2011205
Standard Package 500
Win Source Part Number 996478-M22-2011205
Ultra Librarian 3D Model Ultra Librarian M22-2011205 CAD Model

Description

The M22 series male pin header connector is a 12 position board to board connector that features push-pull fastening and through-hole mounting.

  • Positions: 12
  • Mounting: Through-Hole
  • Fastening: Push-Pull
  • Insulation Material: Polyamide
  • Contact Material: Phosphor Bronze
  • Contact Finish: Gold
  • Voltage Rating: -
  • Temperature Range: -55°C to 105°C
  • Contact Length (Mating): 0.138"
  • Contact Length (Post): 0.134"
  • Overall Contact Length: 0.331"
  • Contact Shape: Square
  • Shrouded: Unshrouded
  • Pitch-Mating: 0.079"
  • Row Spacing-Mating: -
  • Current Rating: 1A per Contact
  • Packaging: Bulk
  • Application: General-Purpose
