09644117800 HARTING – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

09644117800

Part No 09644117800
Manufacturer HARTING
Catalog D-Sub, D-Shaped Connectors - Assemblies
Description CONN D-SUB RCPT 37POS SOLDER CUP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Connector Style D-Sub
Connector Type Receptacle, Female Sockets
Number of Positions 37
Number of Rows 2
Mounting Type Free Hanging (In-Line)
Shell Size, Connector Layout 4 (DC, C)
Contact Type Signal
Flange Feature Housing/Shell (Unthreaded)
Termination Solder Cup
Shell Material, Finish Steel, Tin Plated
Material Flammability Rating UL94 V-0
Current Rating (Amps) 7.5A
Features Filter
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1623565-09644117800
Ultra Librarian 3D Model Ultra Librarian 09644117800 CAD Model
