Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr GOOD-ARK Electronics
Package Tape & Reel
Product Status Active
Diode Type Single Phase
Technology Schottky
Voltage - Peak Reverse (Max) 100 V
Current - Average Rectified (Io) 1 A
Voltage - Forward (Vf) (Max) @ If 0.85 V @ 1 A
Current - Reverse Leakage @ Vr 500 µA @ 100 V
Temperature Range - Operating -55°C ~ 125°C (TJ)
Mounting Type Surface Mount
Package / Case TO-269AA, 4-BESOP
Supplier Device Package TO-269AA (MBS)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 632886-MB110S
Ultra Librarian 3D Model Ultra Librarian MB110S CAD Model

Description

The MB110S is a bridge rectifier diode in a single-phase configuration.

  • Package: tape & reel
  • Standard Package: 3,000 pieces
  • Average Rectified Current: 1 A
  • Forward Voltage: 0.85 V @ 1 A
  • Reverse Leakage Current: 500 µA @ 100 V
  • Mounting Type: surface mountable
  • Package/Case: TO-269AA, 4-BESOP
  • Manufacturer: GOOD-ARK Electronics
  • Market Status: active
