1N2133A GeneSiC Semiconductor
Same model may have multiple batches, images only for reference.

1N2133A

Part No 1N2133A
Manufacturer GeneSiC Semiconductor
Catalog Diodes, Rectifiers - Single
Description 35,40,and 60 Amp Power Silicon Rectifier Diodes | DIODE GEN PURP 300V 60A DO5
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer GeneSiC Semiconductor
Packaging Bulk
Diode Type Standard
Voltage - DC Reverse (Vr) (Maximum) 300V
Current - Average Rectified (Io) 60A
Voltage - Forward (Vf) (Maximum) at If 1.1V at 60A
Speed Standard Recovery >500ns, > 200mA (Io)
Current - Reverse Leakage at Vr 10μA at 50V
Mounting Style Chassis, Stud Mount
Manufacturer Package DO-203AB, DO-5, Stud
Supplier Device Package DO-5
Operating Temperature - Junction -65°C ~ 200°C
Family Part Number 1N2133
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 1121643-1N2133A
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 1N2133A CAD Model

Description

The 1N2133A is a standard recovery diode from GeneSiC Semiconductor.

  • Maximum DC Reverse Voltage: 300V
  • Forward Voltage: 1.1V @ 60A
  • Operating Temperature Range: -65°C to 200°C
  • Package: DO-5
  • Mounting: Chassis and stud mountable
  • Average Rectified Current: 60A
