MPXH6250AC6T1 Freescale Semiconductor - NXP MPXH6250AC6T1 Real Image MPXH6250AC6T1 real image 2 MPXH6250AC6T1 label picture MPXH6250AC6T1 label picture 3
Same model may have multiple batches, images only for reference.
MPXH6250AC6T1 Freescale Semiconductor - NXP MPXH6250AC6T1 Real Image MPXH6250AC6T1 real image 2 MPXH6250AC6T1 label picture MPXH6250AC6T1 label picture 3
MPXH6250AC6T1 Freescale Semiconductor - NXP MPXH6250AC6T1 Real Image MPXH6250AC6T1 real image 2 MPXH6250AC6T1 label picture MPXH6250AC6T1 label picture 3
Same model may have multiple batches, images only for reference.

MPXH6250AC6T1

Part No MPXH6250AC6T1
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description SENSOR 36.26PSIA 0.13" 4.9V SSOP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Pressure Sensors, Transducers
Mfr Freescale Semiconductor - NXP
Series MPXH6250A
Package Bulk
Product Status Active
Applications Board Mount
Pressure Type Absolute
Operating Pressure 2.9PSI ~ 36.26PSI (20kPa ~ 250kPa)
Output Type Analog Voltage
Output 0.3 V ~ 4.9 V
Accuracy ±1.5%
Voltage - Supply 4.74V ~ 5.46V
Port Size Male - 0.13" (3.3mm) Tube
Port Style Barbless
Features Temperature Compensated
Termination Style Gull Wing
Maximum Pressure 145.04PSI (1000kPa)
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 8-SOIC (0.335", 8.50mm Width), Top Port
Supplier Device Package 8-SSOP
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.31.0001
Win Source Part Number 240086-MPXH6250AC6T1
Ultra Librarian 3D Model Ultra Librarian MPXH6250AC6T1 CAD Model

Description

The MPXH6250AC6T1 is a pressure sensor designed for board mount applications.

  • Series: MPXH6250A
  • Termination Style: Gull wing
  • Feature: Temperature compensated
  • Pressure Sensor Type: Absolute
  • Pressure Range: 2.9PSI to 36.26PSI (20kPa to 250kPa)
  • Output Type: Analog voltage
  • Output Range: 0.3V to 4.9V
  • Accuracy: ±1.5%
  • Package: Bulk
  • Port Size: Male 0.13" (3.3mm) tube
  • Mounting: Surface mountable
  • Port Package: Top port
  • Voltage Supply Range: 4.74V to 5.46V
  • Operating Temperature: -40°C to 125°C
  • Manufacturer: Freescale Semiconductor - NXP
  • Status: Active
