Same model may have multiple batches, images only for reference.
MPX2050DP Real Image
Same model may have multiple batches, images only for reference.

MPX2050DP

Part No MPX2050DP
Manufacturer Freescale Semiconductor - NXP
Catalog Pressure Sensors, Transducers
Description Pressure Sensor 0kPa to 50kPa Differential 4-Pin Case 344C-01 Tray / IC PRESSURE SENSOR 4-PIN
Datasheet
MPX2050DP Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer NXP
Status Active
Pressure Type Differential
Operating Pressure 7.25 PSI (50 kPa)
Output Type Wheatstone Bridge
Output 0 mV to 40 mV (10V)
Supply Voltage - Operating 10 V to 16 V
Port Size Male - 0.19" (4.93mm) Tube, Dual
Port Style Barbed
Features Temperature Compensated
Termination Style PCB
Maximum Pressure 29.01 PSI (200 kPa)
Temperature Range - Operating -40°C to 125°C
Win Source Part Number 059497-MPX2050DP
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MPX2050D
Introduction Date January 01, 1992
ECCN EAR99
Halogen Free Not Compliant
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian MPX2050DP CAD Model

Description

The MPX2050DP is a differential pressure sensor manufactured by NXP.

  • Applications: automotive and industrial
  • Pressure Range: 7.25 PSI (50 kPa) to 29.01 PSI (200 kPa)
  • Output Range: 0 mV to 40 mV (10V)
  • Port Size: male - 0.19" (4.93mm) tube, dual
  • Port Style: barbed
  • Temperature Range: -40°C to 125°C
  • Win Source Part Number: 059497-MPX2050DP
  • Product Status: active
  • Popularity: high
