MPC8313CVRAFFB Real Image MPC8313CVRAFFB Real Image1 MPC8313CVRAFFB Real Image2
Same model may have multiple batches, images only for reference.
MPC8313CVRAFFB Real Image MPC8313CVRAFFB Real Image1 MPC8313CVRAFFB Real Image2
MPC8313CVRAFFB Real Image MPC8313CVRAFFB Real Image1 MPC8313CVRAFFB Real Image2
Same model may have multiple batches, images only for reference.

MPC8313CVRAFFB

Part No MPC8313CVRAFFB
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microprocessors
Description IC MPU MPC83XX 333MHZ 516BGA
Datasheet
MPC8313CVRAFFB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Obsolete(EOL)
Core Processor PowerPC e300c3
Number of Cores/Bus Width 1 Core, 32-Bit
Speed(Frequency) 333MHz
RAM Controllers DDR, DDR2
Graphics Acceleration No
Ethernet 10/100/1000 Mbps (2)
USB USB 2.0 + PHY (1)
Voltage - I/O 1.8V, 2.5V, 3.3V
Temperature Range - Operating -40°C to 105°C (TA)
Security Package / Case 516-BBGA Exposed Pad
Case / Package 516-TEPBGA (27x27)
Additional Interfaces DUART, HSSI, I2C, PCI, SPI
Win Source Part Number 135593-MPC8313CVRAFFB
Ultra Librarian 3D Model Ultra Librarian MPC8313CVRAFFB CAD Model

Description

The NXP MPC8313CVRAFFB is a PowerPC e300c3 core processor with 1 core and 32-bit bus width.

  • Co-processors/DSP: None
  • RAM Controllers: DDR and DDR2
  • Graphics Acceleration: No graphics acceleration
  • Display & Interface Controllers: No display & interface controllers
  • Ethernet: 10/100/1000 Mbps
  • USB: 2.0 + PHY
  • Voltage I/O: 1.8V, 2.5V, and 3.3V
  • Additional Interfaces: DUART, HSSI, I2C, PCI, and SPI
  • Category: Integrated circuits
  • Status: Obsolete (EOL)
  • Temperature Range: -40°C to 105°C (TA)
  • Package: 516-TEPBGA (27x27)
  • Speed: 333MHz
  • Security Package/Case: 516-BBGA Exposed Pad
