MC68340FE25E Real Image MC68340FE25E Real Image1 MC68340FE25E Real Image2 MC68340FE25E Real Image3 MC68340FE25E Real Image4
Same model may have multiple batches, images only for reference.
MC68340FE25E Real Image MC68340FE25E Real Image1 MC68340FE25E Real Image2 MC68340FE25E Real Image3 MC68340FE25E Real Image4
MC68340FE25E Real Image MC68340FE25E Real Image1 MC68340FE25E Real Image2 MC68340FE25E Real Image3 MC68340FE25E Real Image4
Same model may have multiple batches, images only for reference.

MC68340FE25E

Part No MC68340FE25E
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microprocessors
Description IC MPU M683XX 25MHZ 144CQFP
Datasheet
MC68340FE25E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Obsolete(EOL)
Core Processor CPU32
Number of Cores/Bus Width 1 Core, 32-Bit
Speed(Frequency) 25MHz
RAM Controllers DRAM
Graphics Acceleration No
Voltage - I/O 5.0V
Temperature Range - Operating 0°C to 70°C (TA)
Security Package / Case 144-BCQFP
Case / Package 144-CQFP (26.77x26.77)
Additional Interfaces USART
Win Source Part Number 044464-MC68340FE25E
Ultra Librarian 3D Model Ultra Librarian MC68340FE25E CAD Model

Description

The MC68340FE25E is an obsolete (EOL) integrated circuit (IC) manufactured by NXP.

  • IC Family: CPU32
  • Core Processor: 32-bit
  • Speed: 25MHz
  • Applications: Automotive, industrial, and telecommunications
  • Case/Package: 144-CQFP (26.77x26.77)
  • Graphics Acceleration: No
  • Display & Interface Controllers: No
  • Ethernet: No
  • SATA: No
  • Voltage - I/O: 5.0V
  • Interface: USART
  • Status: Obsolete (EOL)
