MC13213R2 Real Image
Same model may have multiple batches, images only for reference.

MC13213R2

Part No MC13213R2
Manufacturer Freescale Semiconductor - NXP
Catalog RF Transceiver ICs
Description IC RF TXRX+MCU 802.15.4 71-VFLGA
Datasheet
MC13213R2 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer NXP
Packaging Reel - TR
Status Not For New Designs
Type TxRx + MCU
RF Family/Standard 802.15.4
Protocol Zigbee
Modulation DSSS, O-QPSK
Frequency 2.4GHz
Data Rate (Max) 250kbps
Power - Output 3dBm
Sensitivity -92dBm
Memory Size 60kB Flash, 4kB RAM
Serial Interfaces I2C, SPI
GPIO 32
Supply Voltage - Operating 2 V to 3.4 V
Current - Receiving 37mA
Current - Transmitting 30mA
Temperature Range - Operating -40°C to 85°C
Dimension 71-VFLGA
Win Source Part Number 074439-MC13213R2
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MC13213R2 CAD Model

Description

The NXP 074439-MC13213R2 is a TxRx+MCU electronic component that operates at a frequency of 2.4GHz and uses Zigbee protocol.

  • Memory: 60kB Flash and 4kB RAM
  • Power Output: 3dBm
  • Sensitivity: -92dBm
  • Data Rate: 250kbps
  • Modulation: DSSS and O-QPSK
  • Serial Interfaces: I2C and SPI
  • GPIOs: 32
  • Current Consumption (Receiving): 37mA
  • Current Consumption (Transmitting): 30mA
  • Category: RF/IF and RFID
  • Recommendation: Not recommended for new designs
  • Temperature Range: -40°C to 85°C
  • Operating Voltage: 2V to 3.4V
