DSP56F801FA80E Real Image DSP56F801FA80E real image
Same model may have multiple batches, images only for reference.
DSP56F801FA80E Real Image DSP56F801FA80E real image
DSP56F801FA80E Real Image DSP56F801FA80E real image
Same model may have multiple batches, images only for reference.

DSP56F801FA80E

Part No DSP56F801FA80E
Manufacturer Freescale Semiconductor - NXP
Catalog Embedded - Microcontrollers
Description IC MCU 16BIT 16KB FLASH 48LQFP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer NXP
Packaging Tray
Status Active
Core Processor 56800
Part Core Size 16-Bit
Speed(Frequency) 80MHz
Number of I/O 11
Program Memory Size 16KB (8K x 16)
Program Memory Type FLASH
Data RAM Size 1K x 16
Supply Voltage - Operating 3 V to 3.6 V
Data Converters A/D 8x12b
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 48-LQFP (7x7)
Win Source Part Number 143997-DSP56F801FA80E
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian DSP56F801FA80E CAD Model

Description

Overview of DSP56F801FA80E

The DSP56F801FA80E is a performance-oriented digital signal controller with an emphasis on versatility and efficient design. It is suitable for applications where high-speed processing and cost-effective implementation are critical.

Features and Benefits

  • 80 MHz clock frequency delivering exceptional processing speeds and real-time response.
  • Optimized power consumption supporting longer device operation in portable systems.
  • Comprehensive peripheral integration facilitating simplified application development.

Applications

  • Advanced audio and speech recognition
  • Intelligent motor controllers
  • Embedded networking solutions
  • Robust industrial automation

The DSP56F801FA80E combines speed, efficiency, and integration to meet the demands of modern embedded applications, enabling the development of innovative solutions.
