RHRP15120 Real Image RHRP15120 real image5156
Same model may have multiple batches, images only for reference.
RHRP15120 Real Image RHRP15120 real image5156
RHRP15120 Real Image RHRP15120 real image5156
Same model may have multiple batches, images only for reference.

RHRP15120

Part No RHRP15120
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 1.2KV 15A TO220AC
Datasheet
RHRP15120 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1200V (1.2kV)
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Max) @ If 3.2V @ 15A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 75ns
Current - Reverse Leakage @ Vr 100μA @ 1200V
Mounting Through Hole
Case / Package TO-220-2L
Operating Temperature - Junction -65°C to 175°C
Win Source Part Number 092137-RHRP15120
Family Name RHRP15120
Introduction Date January 14, 2002
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Quantity per package 800
Ultra Librarian 3D Model Ultra Librarian RHRP15120 CAD Model

Description

The RHRP15120 is a standard diode type electronic component manufactured by Fairchild/ON Semiconductor.

  • Package: Tube/Rail
  • Mounting: Through-Hole
  • Maximum Voltage for DC Reverse: 1200V (1.2kV)
  • Average Rectified Current: 15A
  • Forward Voltage: 3.2V @ 15A
  • Reverse Recovery Time: 75ns
  • Current for Reverse Leakage @ Vr: 100μA @ 1200V
  • Speed: Fast Recovery = 200mA (Io)
  • Operating Temperature: -65°C to 175°C
  • Active: Yes
  • Halogen-Free: Yes
  • Estimated EOL Date: 2023
  • Supply and Demand Status: Limited
  • Quantity per Package: 800
