NC7SZ86P5X Real Image NC7SZ86P5X Real Image
Same model may have multiple batches, images only for reference.
NC7SZ86P5X Real Image NC7SZ86P5X Real Image
NC7SZ86P5X Real Image NC7SZ86P5X Real Image
Same model may have multiple batches, images only for reference.

NC7SZ86P5X

Part No NC7SZ86P5X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters
Description IC GATE XOR 1CH 2-INP SC-70-5
Datasheet
NC7SZ86P5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Logic Type XOR (Exclusive OR)
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 32mA, 32mA
Max Propagation Delay @ V, Max CL 5.4ns @ 5V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 024852-NC7SZ86P5X
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian NC7SZ86P5X CAD Model

Description

The Fairchild/ON Semiconductor electronic component, with Win Source Part Number 024852-NC7SZ86P5X, is a high popularity Integrated Circuit.

  • Logic Type: XOR (Exclusive OR)
  • Mounting: SMD (SMT)
  • Case/Package: SC-70-5
  • Application Field: industrial
  • Package: 3k pcs
