NC7SZ04M5X

Name: NC7SZ04M5X
Brand: Fairchild/ON Semiconductor
SKU: 250057
Availability: InStock
Rating: 4.85 (320 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	NC7SZ04M5X
Manufacturer	Fairchild/ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	IC INVERTER SGL TINYLOGIC SOT-23
Datasheet	NC7SZ04M5X Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	1
Number of Inputs	1
Supply Voltage - Operating	1.65 V to 5.5 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	32mA, 32mA
Max Propagation Delay @ V, Max CL	4.3ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	SOT-23-5
Dimension	SC-74A, SOT-753
Win Source Part Number	024801-NC7SZ04M5X
Family Name	NC7SZ04
Introduction Date	November 16, 1999
ECCN	EAR99
Country of Origin	China, Philippines
Halogen Free	Compliant
Estimated EOL Date	2025
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian NC7SZ04M5X CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor is a high-quality inverter component that is designed to provide reliable and efficient performance.

Win Source Part Number: 024801-NC7SZ04M5X
Packaging: Reel - TR
Mounting: SMD (SMT)
Logic type: inverter
Number of inputs: 1
Current-output high: 32mA
Current-output low: 32mA
