NC7SP58L6X Fairchild/ON Semiconductor – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

NC7SP58L6X

Part No NC7SP58L6X
Manufacturer Fairchild/ON Semiconductor
Catalog Logic - Gates and Inverters - Multi - Function, Configurable
Description IC MF CFG 1-CIR 3-IN 6MICROPAK
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Logic Type Configurable Multiple Function
Number of Circuits 1
Number of Inputs 3
Schmitt Trigger Input No
Output Type Single-Ended
Current - Output High, Low 2.6mA, 2.6mA
Voltage - Supply 0.9V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Case / Package 6-UFDFN
Supplier Device Package 6-MicroPak
Package Bulk
Supply and Demand Status Normal
Win Source Part Number 1500909-NC7SP58L6X
Ultra Librarian 3D Model Ultra Librarian NC7SP58L6X CAD Model

Description

N
