NC7S32P5X

Name: NC7S32P5X
Brand: Fairchild/ON Semiconductor
SKU: 249941
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	NC7S32P5X
Manufacturer	Fairchild/ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	OR Gate 1-Element 2-IN CMOS 5-Pin SC-70 T/R / IC GATE OR 1CH 2-INP SC-70-5
Datasheet	NC7S32P5X Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	OR Gate
Number of Circuits	1
Number of Inputs	2
Supply Voltage - Operating	2 V to 6 V
Current - Quiescent (Max)	1μA
Current - Output High, Low	2.6mA, 2.6mA
Logic Level - Low	0.5V
Logic Level - High	1.5V
Max Propagation Delay @ V, Max CL	17ns @ 6V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	SC-70-5
Dimension	5-TSSOP, SC-70-5, SOT-353
Win Source Part Number	024737-NC7S32P5X
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Quantity per package	3k pcs
Family Name	NC7S32
Introduction Date	June 12, 2000
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian NC7S32P5X CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor NC7S32P5X is an OR gate logic type integrated circuit from Fairchild/ON Semiconductor.

Circuit Count: Single
Number of Inputs: Two
Mounting Technology: SMD (SMT)
Current Output High: 2.6mA
Current Output Low: 2.6mA
Maximum Propagation Delay: 17ns @ 6V and 50pF
Quiescent Current: 1μA
Low Logic Level: 0.5V
High Logic Level: 1.5V
Family: NC7S32
Package: SC-70-5
Dimension: 5-TSSOP, SC-70-5, SOT-353
Supply Voltage: 2V to 6V
Supply and Demand Status: Sufficient
