LMV321AP5X Real Image LMV321AP5X real image1794
Same model may have multiple batches, images only for reference.
LMV321AP5X Real Image LMV321AP5X real image1794
LMV321AP5X Real Image LMV321AP5X real image1794
Same model may have multiple batches, images only for reference.

LMV321AP5X

Part No LMV321AP5X
Manufacturer Fairchild/ON Semiconductor
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP VFB 1.4MHZ RRO SC70-5
Datasheet
LMV321AP5X Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Amplifier Type Voltage Feedback
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 1.5 V/μs
Gain Bandwidth Product (GBP) 1.4MHz
Current - Input Bias 1nA
Voltage - Input Offset 1mV
Operating Supply Current 100μA
Channel Output Current 34mA
Supply Voltage - Operating 2.7 V to 5.5 V, ±1.35 V to 2.75 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SC-70-5
Win Source Part Number 019576-LMV321AP5X
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian LMV321AP5X CAD Model

Description

The Fairchild/ON Semiconductor LMV321AP5X is a voltage feedback amplifier with a gain bandwidth product (GBP) of 1.4MHz. It has a single circuit and is mounted in an SMD (SMT) package. The output type is rail-to-rail with a slew rate of 1.5 V/μs. It has an operating supply current of 100μA and a channel output current of 34mA. The amplifier has a voltage input offset of 1mV and a current input bias of 1nA. It operates in a temperature range of -40°C to 125°C and is packaged in an SC-70-5 package. The package contains 3k pcs.
