FAN2103EMPX

Part No FAN2103EMPX
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description 3A, 24V Input Integrated Synchronous Buck Regulator
Datasheet
FAN2103EMPX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Fairchild/ON Semiconductor
Series TinyBuck
Packaging Reel - TR
Function Step-Down
Output Configuration Positive
Topology Buck
Output Type Adjustable
Number of Outputs 1
Input Voltage MIN 3V
Voltage Input MAX 24V
Output Voltage 0.8V
Output Voltage MAX 21.6V
Output Current 3A
Frequency - Switching 300kHz ~ 600kHz
Synchronous Rectifier Yes
Operating Temperature Range -40°C ~ 85°C (TA)
Mounting SMD
Package 25-WQFN Exposed Pad
Manufacturer Package 25-MLP (5x6)
Win Source Part Number 1173267-FAN2103EMPX
Manufacturer Homepage www.fairchildsemi.com
Family Name FAN2103
Introduction Date December 06, 2007
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2019
Popularity Medium
Supply and Demand Status Limited
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FAN2103EMPX CAD Model

Description

The Fairchild/ON Semiconductor FAN2103EMPX is an adjustable output type step-down integrated circuit that operates within a temperature range of -40°C to 85°C (TA).

  • Temperature Range: -40°C to 85°C (TA)
  • Frequency Switching: 300kHz ~ 600kHz
  • Rectifier: Synchronous
  • Number of Outputs: 1
  • Output Configuration: Positive
  • Maximum Output Voltage: 21.6V
  • Input Voltage Range: 3V to 24V
  • Output Current: 3A
  • Series: TinyBuck
  • Mounting: SMD
  • Package: 25-WQFN exposed pad
  • Estimated EOL Date: 2019
  • Halogen-Free: Compliant
