1N4448WT Real Image 1N4448WT real image14950
Same model may have multiple batches, images only for reference.
1N4448WT Real Image 1N4448WT real image14950
1N4448WT Real Image 1N4448WT real image14950
Same model may have multiple batches, images only for reference.

1N4448WT

Part No 1N4448WT
Manufacturer Fairchild/ON Semiconductor
Catalog Diodes, Rectifiers - Single
Description Rectifier Diode Small Signal Switching 75V 4ns 2-Pin SOD-523 T/R / DIODE GEN PURP 75V 200MA SOD523F
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 75V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 1V @ 100mA
Reverse Recovery Time (trr) 4ns
Current - Reverse Leakage @ Vr 5μA @ 75V
Capacitance @ Vr, F 4pF @ 0V, 1MHz
Mounting SMD (SMT)
Case / Package SOD-523F
Operating Temperature - Junction -55°C to 150°C
Win Source Part Number 1002117-1N4448WT
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Quantity per package 8k pcs
Family Name 1N4448WT
Introduction Date November 30, 2005
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian 1N4448WT CAD Model

Description

The 1N4448WT is a standard diode manufactured by Fairchild/ON Semiconductor.

  • Application: Rectification and Switching
  • DC Reverse Voltage: 75V
  • Reverse Recovery Time: 4ns
  • Current Average Rectified: 200mA
  • Voltage Forward: 1V @ 100mA
  • Package Type: SOD-523F
  • Temperature Range: -55°C to 150°C
  • Popularity: High
  • Supply and Demand Status: Sufficient
