Same model may have multiple batches, images only for reference.

15-21UYC/S530-A3/TR8

Name: 15-21UYC/S530-A3/TR8
Brand: Everlight Electronics Co Ltd
SKU: 415812
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	15-21UYC/S530-A3/TR8
Manufacturer	Everlight Electronics Co Ltd
Catalog	LED Indication - Discrete
Description	LED YELLOW CLEAR 1206 SMD
Datasheet	15-21UYC/S530-A3/TR8 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Optoelectronics
Manufacturer	Everlight Electronics Co Ltd
Packaging	Reel - TR
Status	Active
Color	Yellow
Lens Color	Colorless
Lens Transparency	Clear
Millicandela Rating	57mcd
Lens Style/Size	Rectangle with Flat Top, 2.00mm x 1.50mm
Forward Voltage	2V
Current - Test	20mA
Viewing Angle	130°
Mounting	SMD (SMT)
Wavelength - Dominant	589nm
Wavelength - Peak	591nm
Case / Package	1206
Height (Max)	1.00mm
Win Source Part Number	1001523-15-21UYC/S530-A3/TR8
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian 15-21UYC/S530-A3/TR8 CAD Model

Alternative Products

Description

The Everlight Electronics Co Ltd 1001523-15-21UYC/S530-A3/TR8 is a yellow surface-mount LED with a rectangle flat top lens.

Forward Voltage: 2V
Viewing Angle: 130 degrees
Lens Color: Clear, colorless
Millicandela Rating: 62mcd
Lens Style/Size: 2.00mm x 1.50mm
Current-Test: 20mA
Wavelength-Dominant: 589nm
Peak Wavelength: 591nm
Height: 1.00mm
Package: Reel - TR
Category: Optoelectronics
Status: Active
