SG-615PT-28.3220MC2

Part No SG-615PT-28.3220MC2
Manufacturer Epson Company
Catalog Oscillators
Description OSC XO 28.322MHZ CMOS TTL SMD / 28.322 MHz XO (Standard) CMOS, TTL Oscillator 5V Enable/Disable 4-SOJ, 5.08mm pitch
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Crystals, Oscillators, Resonators>Oscillators
Mfr EPSON
Series SG-615
Package Cut Tape (CT)
Product Status Obsolete
Base Resonator Crystal
Type XO (Standard)
Frequency 28.322 MHz
Function Enable/Disable
Output CMOS, TTL
Voltage - Supply 5V
Frequency Stability ±100ppm
Temperature Range - Operating -20°C ~ 70°C
Current - Supply (Max) 35mA
Mounting SMD (SMT)
Package / Case 4-SOJ, 5.08mm pitch
Dimension 0.551" L x 0.341" W (14.00mm x 8.65mm)
Height - Seated (Max) 0.185" (4.70mm)
Current - Supply (Disable) (Max) 12mA
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8542.39.0001
Other Names SE2301,SE2301CT,SE2301-ND,SE2301TR,SG-615PT28.3220,SG615PT283220MC2
Standard Package 500
Win Source Part Number 1171400-SG-615PT-28.3220MC2
Ultra Librarian 3D Model Ultra Librarian SG-615PT-28.3220MC2 CAD Model

Description

The SG-615PT-28.3220MC2 is an oscillator from the SG-615 series, manufactured by EPSON.

  • Package: cut tape (CT)
  • Standard Package: 500
  • Mounting: SMD (SMT)
  • Frequency: 28.322 MHz
  • Output: CMOS, TTL
  • Frequency Stability: ±100ppm
  • Current Supply (Max): 35mA
  • Current Supply (Disable) (Max): 12mA
  • Voltage Supply: 5V
  • Operating Temperature Range: -20°C ~ 70°C
  • Dimension: 0.551" L x 0.341" W (14.00mm x 8.65mm)
  • MSL Level: 1
  • Base Resonator: crystal
  • RoHS Compliant: No
