B59840C0120A070 Real Image
Same model may have multiple batches, images only for reference.

B59840C0120A070

Part No B59840C0120A070
Manufacturer EPCOS (TDK)
Catalog PTC Resettable Fuses
Description PTC RESET FUSE 265V 330MA RADIAL / Ceramic PTC Resettable Fuse 265V 330 mA Ih Through Hole Radial, Disc
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>PTC Resettable Fuses
Mfr EPCOS (TDK)
Series -
Package Bulk
Type Ceramic
Voltage - Max 265V
Current - Hold (Ih) (Max) 330 mA
Current - Trip (It) 660 mA
Current - Max 4.1 A
Resistance - 25°C (Typ) 6 Ohms
Temperature Range - Operating 0°C ~ 60°C
Ratings -
Mounting Type Through Hole
Package / Case Radial, Disc
Size / Dimension 0.689" Dia x 0.197" T (17.50mm x 5.00mm)
Height - Seated (Max) 0.827" (21.00mm)
Thickness (Max) -
Lead Spacing 0.197" (5.00mm)
Approval Agency UR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
Standard Package 500 pcs
Win Source Part Number 1381537-B59840C0120A070
Ultra Librarian 3D Model Ultra Librarian B59840C0120A070 CAD Model

Description

The PTC resettable fuse is a ceramic component designed for circuit protection applications by EPCOS (TDK).

  • Diameter: 0.689" (17.50mm)
  • Height: 0.197" (5.00mm)
  • Voltage Rating: 265V
  • Maximum Current Rating: 4.1 A
  • Hold Current: 330 mA
  • Trip Current: 660 mA
  • Mounting Type: Through-Hole
  • Package: Bulk
  • Standard Package: 500 pieces
  • Temperature Range: 0°C to 60°C
  • Approval Agency: UR
  • Moisture Sensitivity Level: 1 (unlimited)
