Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr EPC
Series eGaN®
Package Bulk
Type Power Management
Function Half H-Bridge Driver (External FET)
Embedded No
Utilized IC / Part EPC2106
Primary Attributes 100V, 3A Max Output GaNFET Capability
Supplied Contents Board(s)
Secondary Attributes GaNFET Driver Circuit Uses 7V ~ 12V
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8543.70.9860
Other Names 917-1111
Standard Package 1
Win Source Part Number 1130884-EPC9055
Ultra Librarian 3D Model Ultra Librarian EPC9055 CAD Model

Description

The EPC9055 is an evaluation and demonstration board designed for use with eGaN power management devices.

  • Function: Half H-bridge driver with external FET
  • Maximum Output Capability: 100V and 3A
  • Voltage: Supplied with GaNFET driver circuit that uses 7V to 12V
  • IC/Part Utilized: EPC2106

The EPC9055 is not embedded and utilizes the EPC2106 IC/part. It is available in bulk packaging and is unaffected by REACH.
