WCL3225-1R5-R Real Image
Same model may have multiple batches, images only for reference.

WCL3225-1R5-R

Part No WCL3225-1R5-R
Manufacturer Eaton Bussmann
Catalog Fixed Inductors
Description FIXED IND 1.5UH 450MA 400MOHM SM / 1.5 µH Unshielded Drum Core, Wirewound Inductor 450 mA 400mOhm Max 1210 (3225 Metric)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Eaton - Electronics Division
Series WCL3225
Package Tape & Reel (TR)
Type Drum Core, Wirewound
Material - Core Ceramic
Inductance 1.5 µH
Tolerance ±5%
Current Rating (Amps) 450 mA
Shielding Unshielded
DC Resistance (DCR) 400mOhm Max
Q @ Freq 12 @ 7.96MHz
Frequency - Self Resonant 200MHz
Temperature Range - Operating -40°C ~ 85°C
Inductance Frequency - Test 7.96 MHz
Mounting SMD (SMT)
Package / Case 1210 (3225 Metric)
Supplier Device Package 1210
Dimension 0.138" L x 0.114" W (3.50mm x 2.90mm)
Height - Seated (Max) 0.089" (2.25mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.8000
Other Names 283-WCL3225-1R5-RTR
Standard Package 2,000
Win Source Part Number 1038049-WCL3225-1R5-R
Ultra Librarian 3D Model Ultra Librarian WCL3225-1R5-R CAD Model

Description

The fixed inductor 1038049-WCL3225-1R5-R is a high-performance component used in various electronic devices from Eaton.

  • Inductance: 1.5 μH
  • Seated Height: 0.089 inches (2.25mm)
  • Mounting: SMD (SMT)
  • Tolerance: ±5%
  • Core Material: Ceramic
  • Q @ Freq: 12 @ 7.96MHz
  • Frequency Self-Resonant: 200MHz
  • DC Resistance (DCR): 400mOhm Max
  • Operating Temperature: -40°C to 85°C
  • Packaging: Tape and Reel
