STS232240U301

Name: STS232240U301
Brand: Eaton Bussmann
SKU: 1135542
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	STS232240U301
Manufacturer	Eaton Bussmann
Catalog	TVS - Diodes
Description	TVS DIODE 24VWM 55VC SOT23 / 55V Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount SOT-23
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection>TVS - Diodes
Mfr	Eaton - Electronics Division
Series	BUSSMANN
Package	Tape & Reel
Type	Zener
Unidirectional Channels	2
Voltage - Reverse Standoff (Typ)	24V (Max)
Voltage - Breakdown (Min)	26.7V
Voltage - Clamping (Max) @ Ipp	55V
Current - Peak Pulse (10/1000µs)	5A (8/20µs)
Power - Peak Pulse	350W
Power Line Protection	No
Applications	General Purpose
Capacitance @ Frequency	30pF @ 1MHz
Temperature Range - Operating	-55°C ~ 125°C (TJ)
Mounting	SMD (SMT)
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23
MSL Level	3 (168 Hours)
ECCN	EAR99
HTSUS	8541.10.0080
Other Names	283-STS232240U301DKR,283-STS232240U301TR,283-STS232240U301CT
Standard Package	3,000
Win Source Part Number	1135542-STS232240U301
Ultra Librarian 3D Model	Ultra Librarian STS232240U301 CAD Model

Description

This electronic component is manufactured by Eaton - Electronics Division and has a Win Source Part Number of 1135542-STS232240U301.

Type: Zener Diode
Voltage - Breakdown (Min): 26.7V
Voltage - Clamping (Max) @ Ipp: 55V
Power - Peak Pulse: 350W
Package/Case: TO-236-3, SC-59, SOT-23-3
Unidirectional Channels: 2
Category: Circuit Protection>TVS - Diodes
Standard Package: 3,000
Supply and Demand Status: Balance
