FP1007R3-R23-R Cooper Bussmann, Inc. FP1007R3-R23-R real image
Same model may have multiple batches, images only for reference.
FP1007R3-R23-R Cooper Bussmann, Inc. FP1007R3-R23-R real image
FP1007R3-R23-R Cooper Bussmann, Inc. FP1007R3-R23-R real image
Same model may have multiple batches, images only for reference.

FP1007R3-R23-R

Part No FP1007R3-R23-R
Manufacturer Eaton Bussmann
Catalog Fixed Inductors
Description FIXED IND 230NH 61A 0.29MOHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Eaton Bussmann
Series FLAT-PAC, FP1007
Package Tape & Reel
Product Status Active
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 230 nH
Tolerance ±10%
Current Rating (Amps) 61 A
Current - Saturation (Isat) 48A
Shielding Unshielded
DC Resistance (DCR) 0.29mOhm
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Size / Dimension 0.402" L x 0.307" W (10.20mm x 7.80mm)
Height - Seated (Max) 0.295" (7.50mm)
Standard Package 650 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 843323-FP1007R3-R23-R
Ultra Librarian 3D Model Ultra Librarian FP1007R3-R23-R CAD Model

Description

The 843323-FP1007R3-R23-R is a fixed inductor from Eaton Bussmann. It is part of the FLAT-PAC and FP1007 series, designed to provide reliable inductance in electronic circuits. This drum core, wirewound inductor comes in a tape & reel package and is unshielded.

  • Core Type: Drum Core, Wirewound
  • Package: Tape & Reel
  • Shielding: Unshielded
  • Size: 0.402" L x 0.307" W (10.20mm x 7.80mm)
  • Inductance: 230 nH
  • Maximum Seated Height: 0.295" (7.50mm)
  • Standard Package: 650 pieces
  • Tolerance: ±10%
  • Core Material: Ferrite
  • Mounting Type: Surface Mount
  • Package/Case: Nonstandard
  • DC Resistance (DCR): 0.29mOhm
  • Operating Temperature: -40°C to 125°C
  • Current: 61A
  • Inductance Frequency Test: 100 kHz
  • HTSUS Code: 8504.50.4000
