170M4466 Real Image
Same model may have multiple batches, images only for reference.

170M4466

Part No 170M4466
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE SQUARE 630A 700VAC RECT
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Electrical, Specialty Fuses
Mfr Eaton Bussmann
Package Bulk
Product Status Active
Mounting Type Requires Holder
Fuse Type Square
Current Rating (Amps) 630A
Voltage Rating - AC 700 V
Applications Electrical, Industrial
Features Indicating
Approval Agency CSA, UR
Breaking Capacity @ Rated Voltage 200kA
Package / Case Rectangular, Blade
Size / Dimension 1.969" L x 2.087" W x 2.717" H (50.00mm x 53.00mm x 69.00mm)
Melting I2t 52000
Standard Package 3 pcs
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.10.0040
Win Source Part Number 905463-170M4466
Ultra Librarian 3D Model Ultra Librarian 170M4466 CAD Model

Description

The 835827 electronic component is a square fuse with a voltage rating of 700V. It is designed for circuit protection in electrical and industrial applications.

  • Fuse Type: Square
  • Voltage Rating: 700V
  • Breaking Capacity: 200kA
  • Melting I2t: 52000
  • Package Type: Bulk
  • Mounting Type: Holder Required
  • Size / Dimension: 1.969" L x 2.087" W x 2.717" H (50.00mm x 53.00mm x 69.00mm)
  • Indicating: Yes
  • Approvals: CSA, UR
