170M4460 Real Image
Same model may have multiple batches, images only for reference.

170M4460

Part No 170M4460
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE SQUARE 315A 700VAC RECT / 315A 700 V AC DC Fuse Square Holder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Eaton - Bussmann Electrical Division
Package Bulk
Mounting Type Holder
Fuse Type Square
Current Rating (Amps) 315A
Voltage Rating - AC 700 V
Applications Electrical, Industrial
Features Indicating
Approval Agency CSA, UR
Breaking Capacity @ Rated Voltage 200kA
Package / Case Rectangular, Blade
Dimension 1.969" L x 2.087" W x 2.717" H (50.00mm x 53.00mm x 69.00mm)
Melting I2t 6200
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.10.0040
Standard Package 3
Win Source Part Number 1078488-170M4460
Ultra Librarian 3D Model Ultra Librarian 170M4460 CAD Model

Description

The Eaton-Bussmann Electrical Division 170M4460 is a square, indicating fuse designed for electrical and industrial applications.

  • Manufacturer: Eaton-Bussmann Electrical Division
  • Fuse Type: square
  • Indicating: indicating fuse
  • Application: electrical and industrial applications
  • Voltage Rating: 700 V AC
  • Breaking Capacity @ Rated Voltage: 200kA
  • Dimension: 1.969" L x 2.087" W x 2.717" H (50.00mm x 53.00mm x 69.00mm)
  • Current Rating: 315A
  • Package: rectangular, blade
  • Mounting Type: holder
  • Melting I2t: 6200
  • Alternative Parts: FWP-400A, FWP-350A, FWH-400A, IDSR400.X, IDSR350.X, and L70S350.V
  • ECCN: EAR99
  • Approvals: CSA and UR
  • Standard Package: 3
  • MSL Level: 1 (Unlimited)
