170M3514 Real Image
Same model may have multiple batches, images only for reference.

170M3514

Part No 170M3514
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE 160A 690V 1GN/50 AR UC / AC DC Fuse Square Holder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Eaton - Bussmann Electrical Division
Package Bulk
Mounting Type Holder
Fuse Type Square
Response Time Fast Blow
Dimension 2.323" L x 1.772" W x 2.008" H (59.00mm x 45.00mm x 51.00mm)
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.10.0040
Standard Package 3
Win Source Part Number 1073785-170M3514
Ultra Librarian 3D Model Ultra Librarian 170M3514 CAD Model

Description

The Eaton - Bussmann Electrical Division 1073785-170M3514 fuse is a fast-blow square fuse designed for use in electrical and specialty fuses.

  • Manufacturer: Eaton - Bussmann Electrical Division
  • Fuse Type: square
  • Response Time: fast
  • Mounting Type: holder
  • Standard Package: 3
  • Dimension: 2.323" L x 1.772" W x 2.008" H (59.00mm x 45.00mm x 51.00mm)
  • Voltage Rating for AC: not specified
  • Breaking Capacity @ Rated Voltage: 200kA
  • MSL Level: 1 (unlimited)
  • HTSUS Code: 8536.10.0040
  • Alternative Parts (cross-reference): 170M1320, 170M2617, 170M1420, L70S175.V, LA070URD30LI0200
