170M3441 Real Image
Same model may have multiple batches, images only for reference.

170M3441

Part No 170M3441
Manufacturer Eaton Bussmann
Catalog Electrical, Specialty Fuses
Description FUSE SQUARE 100A 1.3KVAC RECT / 100A 1.3 kV AC DC Fuse Square Holder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection>Electrical, Specialty Fuses
Mfr Eaton - Bussmann Electrical Division
Package Bulk
Mounting Type Holder
Fuse Type Square
Current Rating (Amps) 100A
Voltage Rating - AC 1.3 kV
Applications Electrical, Industrial
Features Indicating
Approval Agency CSA, UR
Breaking Capacity @ Rated Voltage 100kA
Package / Case Rectangular, Blade
Dimension 2.323" L x 1.772" W x 3.189" H (59.00mm x 45.00mm x 81.00mm)
Melting I2t 750
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8535.10.0040
Standard Package 3
Win Source Part Number 1078479-170M3441
Ultra Librarian 3D Model Ultra Librarian 170M3441 CAD Model

Description

The Eaton-Bussmann Electrical Division's circuit protection product is a specialty fuse for electrical and industrial applications.

  • Fuse Type: Square
  • Voltage Rating: 1.3 kV AC
  • Breaking Capacity @ Rated Voltage: 100kA
  • Melting I2t: 750
  • Package/Case: Rectangular, Blade
  • Mounting Type: Holder
  • Dimension: 2.323" L x 1.772" W x 3.189" H (59.00mm x 45.00mm x 81.00mm)
  • Standard Package: 3
  • Indicating: Yes
