Z1SMA56 Diotec Semiconductor AG
Same model may have multiple batches, images only for reference.

Z1SMA56

Part No Z1SMA56
Manufacturer DIOTEC Electronics Corporation
Catalog Diodes - Zener - Single
Description DIODE ZENER 56V 1W DO214AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr DIOTEC Electronics Corporation
Package Tape & Reel
Product Status Active
Voltage - Zener (Nom) (Vz) 56 V
Tolerance ±5%
Power - Max 1 W
Impedance (Max) (Zzt) 70 Ohms
Current - Reverse Leakage @ Vr 1 µA @ 42 V
Voltage - Forward (Vf) (Max) @ If 1 V @ 200 mA
Temperature Range - Operating -50°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package DO-214AC (SMA)
Standard Package 7,500 pcs
MSL Level 1 (Unlimited)
HTSUS 8541.10.0000
Win Source Part Number 700018-Z1SMA56
Ultra Librarian 3D Model Ultra Librarian Z1SMA56 CAD Model

Description

The 700018-Z1SMA56 is a single Zener diode designed for use in discrete semiconductor products.

  • Power Rating: 1W
  • Voltage Tolerance: ±5%
  • Forward Voltage (Vf): 1V @ 200mA
  • Reverse Leakage Current: 1 µA @ 42V.
  • Nominal Zener Voltage (Vz): 56V
  • Maximum Impedance (Zzt): 70 Ohms
  • Mounting: surface mount diode
  • Package: DO-214AC, SMA package
  • Packaging: tape and reel packaging.
  • Operating Temperature Range: -50°C to 150°C.
  • Manufacturer: DIOTEC Electronics Corporation
  • Product Status: currently active in the market.
