SB840 Real Image
Same model may have multiple batches, images only for reference.

SB840

Part No SB840
Manufacturer DIOTEC Electronics Corporation
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 8A DO201
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr DIOTEC Electronics Corporation
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 40 V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Max) @ If 550 mV @ 8 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 500 µA @ 40 V
Mounting Type Through Hole
Package / Case DO-201AA, DO-27, Axial
Supplier Device Package DO-201
Operating Temperature - Junction -50°C ~ 150°C
Standard Package 1,250 pcs
MSL Level Not Applicable
HTSUS 8541.10.0000
Win Source Part Number 663840-SB840
Ultra Librarian 3D Model Ultra Librarian SB840 CAD Model

Description

The 663840-SB840 is a Schottky rectifier diode designed for high-speed rectification in discrete semiconductor applications.

  • Maximum Reverse Voltage: 40V
  • Average Rectified Current: 8A
  • Forward Voltage: 550mV @ 8A
  • Package: Through-hole DO-201AA (DO-27/axial)
  • Operating Temperature Range: -50°C to 150°C
  • Manufacturer: DIOTEC Electronics Corporation
