The DDZ5V6BS-7 is a high-quality Zener diode from Diodes Incorporated, renowned for its precision and reliability in voltage regulation applications. This Zener diode is designed to provide a stable reference voltage for electronics circuits, ensuring consistent performance across a variety of applications.

Key Features

• Nominal Zener Voltage: 5.6V, offering precise voltage regulation for your circuits.
• Power Dissipation: The device has a power dissipation of 500mW, accommodating moderate power requirements efficiently.
• Package: Comes in a compact SOD-323 package, making it suitable for high-density PCB designs and space-constrained applications.
• Low Leakage Current: Exhibits low leakage current, enhancing the overall efficiency of the diode in operation.
• High Surge Capability: Capable of withstanding surge currents, thereby providing additional protection against voltage spikes.
• Temperature Stability: Offers excellent stability over a wide temperature range, maintaining consistent performance.

Applications

The DDZ5V6BS-7 Zener diode is highly versatile and can be used in numerous electronic devices and systems. Some of the common applications include:

• Voltage regulation modules
• Overvoltage protection circuits
• Power management solutions
• Consumer electronics
• Telecommunication devices
• Computer peripherals

Quality and Reliability

Diodes Incorporated ensures that the DDZ5V6BS-7 meets stringent quality standards, providing reliable and consistent performance. The device is RoHS compliant, adhering to environmental regulations and minimizing the use of hazardous substances in electronics. Whether for commercial, industrial, or personal use, the DDZ5V6BS-7 Zener diode is an excellent choice for designers looking for a robust voltage regulation solution.
