The B340AE-13 is a high-performance Schottky barrier rectifier from Diodes Incorporated, designed to meet the needs of a wide range of electronic applications. This rectifier is well-suited for use in power supply operations, where efficient power conversion is critical. With its compact SMA (DO-214AC) package, the B340AE-13 provides a space-saving solution without compromising on power and performance.

Key Features

• High Current Capability: The B340AE-13 is capable of conducting up to 3A of continuous forward current, making it ideal for high current applications.
• Low Forward Voltage Drop: The device features a low forward voltage drop, which enhances system efficiency by minimizing power losses during operation.
• High Surge Capability: This rectifier can withstand high surge currents, providing robust protection against transient voltage spikes that can occur in power circuits.
• Thermal Performance: The SMA package offers excellent thermal performance, ensuring the device operates reliably over a wide temperature range.
• RoHS Compliant: The B340AE-13 complies with RoHS standards, making it an environmentally friendly choice for electronic designs.

Applications

Thanks to its versatile features, the B340AE-13 can be utilized in a variety of applications, including but not limited to:

• Switching power supplies
• Converters
• Free-wheeling diodes
• Reverse battery protection
• DC-DC converters
• Automotive applications

Electrical Characteristics

The B340AE-13 has a maximum repetitive peak reverse voltage of 40V and a maximum DC blocking voltage also up to 40V. Its operating junction temperature ranges from -55°C to +150°C, allowing for a stable performance across various environmental conditions.

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the B340AE-13 is no exception. It is manufactured to the highest standards, ensuring reliability and longevity in the field. The device's robust construction and adherence to industry certifications make it a trusted component in any electronic system.
