S29AL016D90TFI020 Cypress Semiconductor Corp S29AL016D90TFI020 real image
Same model may have multiple batches, images only for reference.
S29AL016D90TFI020 Cypress Semiconductor Corp S29AL016D90TFI020 real image
S29AL016D90TFI020 Cypress Semiconductor Corp S29AL016D90TFI020 real image
Same model may have multiple batches, images only for reference.

S29AL016D90TFI020

Part No S29AL016D90TFI020
Manufacturer Cypress Semiconductor Corp
Catalog Flash
Description 16 MEGABIT CMOS 3.0 VOLT ONLY BOOT SECTOR FLASH MEMORY
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Cypress Semiconductor Corp
Package Type TSOP
Interface Type Parallel
Packaging Tray
Operating Supply Voltage (Max) 3.6(V)
Operating Supply Voltage (Min) 2.7(V)
Operating Temperature (Min) -40C
Programmable Yes
Supply Current 35(mA)
Mounting Surface Mount
Pin Count 48
Number of Words 2M/1M
Program/Erase Volt (Typ) 2.7 to 3.6(V)
Operating Temp Range -40C to 85C
Rad Hardened No
Access Time (Max) 90(ns)
Operating Temperature (Max) 85C
Sync/Async Asynchronous
Operating Temperature Classification Industrial
Density 16777216(Bit)
Operating Supply Voltage (Typ) 3/3.3(V)
Boot Type Bottom
Cell Type NOR
Win Source Part Number 091510-S29AL016D90TFI020
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian S29AL016D90TFI020 CAD Model

Description

The Cypress Semiconductor Corp 091510-S29AL016D90TFI020 is a 48 pin surface mount TSOP package asynchronous parallel interface NOR Flash Memory.

  • Manufacturer: Cypress Semiconductor Corp
  • Package: 48 pin TSOP
  • Mounting Type: Surface Mount
  • Interface: Asynchronous Parallel
  • Memory Type: NOR Flash Memory
  • Density: 16777216 bits
  • Number of Words: 2M/1M
  • Operating Temperature Range: -40C to 85C
  • Operating Temperature Classification: Industrial
  • Operating Supply Voltage Range: 2.7V to 3.6V
  • Typical Voltage: 3/3.3V
  • Access Time: Up to 90ns
  • Supply Current: 35mA
  • Programmable: Yes
  • Boot Type: Bottom
  • Common Usage: Computers and computer peripherals
