CS0505B

Part No CS0505B
Manufacturer CUI Inc.
Catalog Current Transducers
Description CURRENT SENSOR,OPEN LOOP,5A,+5V, / Current Sensor 5A 1 Channel Open Loop Bidirectional Module
Datasheet
CS0505B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers>Current Sensors
Mfr CUI Devices
Series CSXX05B
Package Tray
For Measuring AC
Sensor Type Open Loop
Current - Sensing 5A
Number of Channels 1
Output Ratiometric, Voltage
Frequency DC ~ 40kHz
Linearity ±0.5%
Accuracy ±2.2%
Voltage - Supply 4.75V ~ 5.25V
Response Time 7µs
Current - Supply (Max) 25mA
Temperature Range - Operating -10°C ~ 75°C
Polarization Bidirectional
Mounting Type Through Hole
Package / Case Module
Base Product Number CS0505
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 9030.33.3400
Other Names 102-CS0505B
Standard Package 10
Win Source Part Number 1180246-CS0505B
Ultra Librarian 3D Model Ultra Librarian CS0505B CAD Model

Description

The CS0505B from CUI Devices is a current sensor that has a bidirectional polarization and a current sensing of 5A.

  • Polarization: Bidirectional
  • Current Sensing: 5A
  • Package: Module
  • Standard Package: 10
  • Measurement: AC
  • Sensitivity: -
  • Linearity: ±0.5%
  • Accuracy: ±2.2%
  • Voltage Supply: 4.75V ~ 5.25V
  • Mounting Type: Through hole
  • Operating Temperature Range: -10°C ~ 75°C
  • REACH: Unaffected
  • HTSUS: 9030.33.3400
  • Alternative Names: 102-CS0505B
